Double Twist 4300mm 4.0mm Wire Gabion Making Machine

Certification
China Konson Industrial Co., Ltd. certification
We got three machines form KONSON,the machine is good quality and they provide service of installation and debugging.

—— Hassan Fehmi from Turkey

I imported 80,000 sets gabion boxes.The products and marketing team are both excellent.The gabion got a good mark in quality test.

—— Soriane Morchedi from Algeria

I'm Online Chat Now

Double Twist 4300mm 4.0mm Wire Gabion Making Machine

Double Twist 4300mm 4.0mm Wire  Gabion Making Machine
Double Twist 4300mm 4.0mm Wire  Gabion Making Machine Double Twist 4300mm 4.0mm Wire  Gabion Making Machine

Large Image :  Double Twist 4300mm 4.0mm Wire Gabion Making Machine

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Konson
Certification: CE, ISO9001, SGS test, Chinese Patent
Model Number: KS80100-4.0
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Competitive price
Packaging Details: One 40' Open Top Container, wooden pallet, as your design
Delivery Time: within 30 days in receiving prepayment
Payment Terms: L/C, T/T
Supply Ability: 10 Sets per Month
Detailed Product Description
After-sales Service Provided: Commissioning And Training,Video Technical Support Color: Blue Or As Your Request
Name: Gabion Machine Application: Gabion Box
Voltage: As Request Type: Fully Automatic
Usage: Automatic Control Operation Twisting Number: 2
Product Name: Gabion Mesh Machine
High Light:

4300mm Gabion Making Machine

,

4.0mm Wire Gabion Making Machine

,

4.0mm Wire gabion mesh machine



Weight 15MT Wire Diameter 1.6-4.0mm KS80100-4.0 Double Twist Gabion Making Machine



Gabion mesh machine is also called heavy duty hexagonal wire mesh machine or gabion box machine, which is to produce the hexagonal wire mesh for reinforcement stone box use to protect and support the seawall,hillsides,road and bridge,reservoirs and other civil engineering.







Description
Gabion mesh machine is one kind of special equipment for twisting metal wire hexagonal mesh with big wire, big mesh and wide breadth.

The product has widely purpose, with its good corrosion resistance and oxidation resistance, serves well as strengthen, protection and temperature keeping materials in the form of mesh container, stone cage, isolation wall, boiler cover or poultry fence in construction, petroleum, chemical, breeding, garden and food processing industries.



KS Gabion Machine:

Dimensions 8100mm x 1500mm x 2180mm
Model KS80100-4.0
Mesh size 80x100mm
Twist Double twist
Wire diameter 1.6-4.0mm
PVC wire diameter 3.0-5.5mm
The Max. width 4300mm
Spindle Speed 25r/min
Theoretic output 3.5m/min
Motor power 22.0kw
Weight 15MT







Feature
Our machine has several models for different sizes of meshes.We can accept any special orders from clients.


Gabion mesh machine is the production of the regular hexagon metal mesh professional equipment, and its products are widely used in the petroleum, construction, farming, chemical industry, heating pipes and other pipes wrapped network; it can also used in fence, residential and landscape protection. Gabion mesh machine can also be used for the production of gabion cages, which are widely used to protect and support the seawall, hillsides, road and bridge, reservoirs and other civil engineering works, and it is good material for flood fighting.





Application
Gabion machine is designed to produce hexagonal wire mesh with galvanized low carbon steel wire, suitable for structural, heat insulation, protective, and fencing applications. Most of gabion mesh machines are of horizontal design, ensuring smooth running and high productivity.











Double Twist 4300mm 4.0mm Wire  Gabion Making Machine 0

Double Twist 4300mm 4.0mm Wire  Gabion Making Machine 1



Advantages:



A1. CE certificate.
A2. QC system & timely delivery.
A3. New drive mode.
A4. Automatic oil system.
A5. Overload protect clutch.
A6. High-efficiency: theoretic output = 3.5m/min.
A7. Turbine protection system (Option).
A8. Infrared ray safety (Option).
A9. Automatic stop system (Option).
A10. All of the core parts of machines are processed by our own factory, so the quality can be ensured.
A11. KONSON offer better after-sale service. We can provide 12 months guarantee for all the equipments, we will arrange our engineer to install the machines in your factory and teach your workers how to produce, we will also send accessories and spare parts without any cost.
