Five Twist 25r/Min 80x100mm Mesh Gabion Machine Line

Five Twist 25r/Min 80x100mm Mesh Gabion Machine Line
Five Twist 25r/Min 80x100mm Mesh Gabion Machine Line Five Twist 25r/Min 80x100mm Mesh Gabion Machine Line

Large Image :  Five Twist 25r/Min 80x100mm Mesh Gabion Machine Line

Product Details:
Place of Origin: China
Brand Name: Konson
Certification: CE, ISO9001, SGS, ASTMA, EN, BS standard,TUV
Model Number: KS80100-4.0
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Competitive Price
Packaging Details: One 40'Open Top Container, wooden pallet, as your design
Delivery Time: 30 Days
Supply Ability: 10 Sets per Month
Detailed Product Description
Product Name: Gabion Mesh Machine Gabion Twist: Double Twist Or Five Twist
High Light:

80x100mm Mesh Gabion Machine Line

,

25r/Min Gabion Machine Line

,

25r/Min gabion making machine



Gabion Box Machine Automatic Gabion Production Line 2 x 1 x 1M



KS Gabion Mesh Machine Production Line:





Konson brand Gabion Machine is one kind of special equipment for twisting metal wire hexagonal mesh with big wire, large mesh and wide breadth. The product has widely function, with its good corrosion resistance and oxidation resistance, it serves well as strengthening, protection and temperature keeping materials in the form of mesh container, stone cage, isolation wall, boiler cover or poultry fence in construction, chemical, breeding, garden and food processing industries.





Export to Serbia:



Five Twist 25r/Min 80x100mm Mesh Gabion Machine Line 0





Heavy duty Hexagonal Gabion Mesh Machine Automatic Gabion Box Making

The KS series gabion mesh machines include four main standard parts: Main netting machine, Winding machine, Wire tension device and Spiral coiling machine, it is designed to make gabion of various widths and mesh sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC, GALFAN coated is available.







Main netting machine:



1. Model: KS80100-4.0
2. Mesh size: 80x100mm
3. Twist: Double twist
4. Wire diameter: 1.6-4.0mm
5. PVC wire diameter: 3.0-5.5mm
6. Max. width: 4300mm
7. Spindle Speed:25r/min
8. Theoretic output: 3.5m/min
9. Motor power: 22.0kw
10. Weight: 15MT
11. Dimensions: 8100mm x 1500mm x 2180mm



Five Twist 25r/Min 80x100mm Mesh Gabion Machine Line 1



Advantages:

A1. CE / TUV certificate.
A2. QC system & timely delivery.
A3. New drive mode.
A4. Automatic oil system.
A5. Overload protect clutch.
A6. High-efficiency: theoretic output = 3.5m/min.
A7. Turbine protection system (Option).
A8. Infrared ray safety (Option).
A9. Automatic stop system (Option).
A10. All of the core parts of machines are processed by our own factory, so the quality can be ensured.
A11. KONSON offer better after-sale service. We can provide 12 months guarantee for all the equipments, we will arrange our engineer to install the machines in your factory and teach your workers how to produce, we will also send accessories and spare parts without any cost.



Optional machines:

Five Twist 25r/Min 80x100mm Mesh Gabion Machine Line 2
