Full Automatic Gabion Mesh Machine For Producing Gabion Basket , Gabion Wire Mesh

Full Automatic Gabion Mesh Machine For Producing Gabion Basket , Gabion Wire Mesh
Full Automatic Gabion Mesh Machine For Producing Gabion Basket , Gabion Wire Mesh

Large Image :  Full Automatic Gabion Mesh Machine For Producing Gabion Basket , Gabion Wire Mesh

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Konson
Certification: CE, ISO9001, SGS test, Chinese Patent
Model Number: KS80100-4.0
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Competitive price
Packaging Details: One 40' Open Top Container, wooden pallet, as your design
Delivery Time: within 30 days in receiving prepayment
Payment Terms: L/C, T/T
Supply Ability: 10 Sets per Month
Detailed Product Description
High Light:

gabion production line

,

wire mesh welding machine

Full Automatic Gabion Mesh Machine For Producing Gabion Basket , Gabion Wire Mesh



1. Introduction

Konson brand gabion mesh machine is the professional equipments for producing gabion basket, gabion wire mesh, it is also known as heavy type hexagonal wire netting machine.

Gabion mesh machine includes four main standard parts: Main netting machine, Winding machine, Wire tension device and Spiral coiling machine, it can produce gabions of various widths and mesh sizes.

Full Automatic Gabion Mesh Machine For Producing Gabion Basket , Gabion Wire Mesh 0



Advantages:

A1. CE certificated.
A2. QC system & timely delivery.
A3. New drive mode.
A4. Automatic oil system.
A5. Overload protect clutch.
A6. High-efficiency: theoretic output = 3.5m/min.
A7. Turbine protection system (Option).
A8. Infrared ray safety (Option).
A9. Automatic stop system (Option).
A10. All of the core parts of machines are processed by our own factory, so the quality can be ensured.
A11. KONSON offer better after-sale service. We can provide 12 months guarantee for all the equipments, we will arrange our engineer to install the machines in your factory and teach your workers how to produce, we will also send accessories and spare parts without any cost.





3.Specification:

KS machine is designed to produce hexagonal mesh of various widths and sizes:

MODEL

MESH SIZE

MAX.WIRE DIA.

MAX WIDTH

PRODUCING RATE

KS6080-2.4

60X80

mm

3.0mm

2400mm

>3.3 m/min

KS6080-3.2

3.5mm

3200mm

KS6080-4.0

3.5mm

4300mm

KS80100-2.4

80X100

mm

3.5mm

2400mm

>3.5 m/min

KS80100-3.2

3.5mm

3200mm

KS80100-4.0

4.0mm

4300mm

KS100120-2.4

100X120

mm

3.5mm

2400mm

>3.5 m/min

KS100120-3.2

3.5mm

3200mm

KS100120-4.0

4.0mm

4300mm

KS120150-2.4

120X150

mm

4.0mm

2400mm

>3.8 m/min

KS120150-3.2

4.0mm

3200mm

KS120150-4.0

4.0mm

4300mm
