PVC Coated Gabion Basket Filled With Stone , Electro Galvanized Gabion Box
1. Konson Gabion Basket:
GABIONS (Higher than 1m in height) and MATTRESSES (Less than 1m in height) consist of rectangular units, fabricated from a double-twisted hexagonal mesh.
Filled with stones, gabions become large, flexible and permeable elements from which a broad range of structures may be built. Gabions and mattresses are widely used for hydraulic and geo- technical control such as retaining walls, riverbank protections, weirs, channel linings etc.
1. Flexible. It can tolerate huge forces without breaking or cracking. It can adapt itself to some degree of movement.
2. Durable. If coated with PVC, the life of structure gets longer which is better for hydraulic works.
3. Permeable. Gabion box filled with stones provides an effective permeability throughout the structure.
4. Economical. Especially when the stones to fill the structure are close to the work area. Low maintenance is required for the construction works.
5. Strength. It can absorb the huge amount of energy and is very strong under tension generated by the nature.Well-made gabion structures can exist in perfect condition for many decades.
Gabion also can be manufactured in the following material:
1.Electro galvanized Gabion box
Zinc coating: 220g/m2, 260g/m2, 275g/m2, 290g/m2
2.Hot dip galvanized Gabion Box
3.Galfan Gabion Box (95% Zinc +5% Al )
4.PVC/PE coated Gabion Box
Gabions sizes:2m x 1m x 1m, 3m x 1m x 1m, 4m x 1m x 1m, 2m x 1m x 0.5m,
4m x 1m x 0.5m and customize design is available.
Wire dia :2.2mm, 2.7mm, 3.4mm, 3.9mm and etc.
Hole Size:60x80mm, 80x100mm, 100x120mm, 120x150mm
1.Control and guide of water or flood
2.Flood bank or guiding bank
3.Preventing of rock breaking
4.Water and soil protection
6.Strengthening structure of soil
7.Protection engineering of seaside area.
