|Power:||22kw||System:||PLC Control System|
|Working Width:||4300mm||Mesh Size:||100x120mm|
hexagonal wire mesh machine,
hexagonal wire mesh
High Quality Hexagonal Mesh Machine For Heavy Duty Stone Gabion Box 3x1x1m
Konson gabion machine refers to the machine for making of hexagonal wire netting, it is also known as heavy type hexagonal wire netting machine.
Our machine is specially used to produce the large size and heavy duty hexagonal (galvanized, galfan & PVC wire) wire meshes for the fence and the stone gabions usage. KS series machine has several models for different sizes of meshes and the maximum netting width is up to 4300mm. We can also supply the complete production line for your whole netting workshop.
The KS series gabion mesh machines include four main standard parts: Main netting machine, Winding machine, Wire tension device and Spiral coiling machine, it can produce gabions of various widths and mesh sizes.
KS Hexagonal Mesh Machine
1. Model: KS100120-4.0
2. Mesh size: 100x120mm
3. Twist: Double twist
4. Wire diameter: 1.6-4.0mm
5. PVC wire diameter: 3.0-5.5mm
6. Max. width: 4300mm
7. Spindle Speed: 25r/min
8. Theoretic output: 3.5m/min
9. Dimensions: 8100mm x 1500mm x 2180mm
KS machine is designed to produce hexagonal mesh of various widths and sizes:
We can also manufacture special size machine according to customer request.
KS series wire mesh machine is only for export, we exported our equipments to Russia, Turkey, Poland, Croatia, Bulgaria, Algeria, Morocco, Ethiopia and etc.
Your any enquiry will be replied within 12 hours.
Loading the equipments, exported to Russia:
