Gabion Mesh PVC Woven Hexagonal Galvanised Welded Wire Mesh Fence Netting

Gabion Mesh PVC Woven Hexagonal Galvanised Welded Wire Mesh Fence Netting
Gabion Mesh PVC Woven Hexagonal Galvanised Welded Wire Mesh Fence Netting

Large Image :  Gabion Mesh PVC Woven Hexagonal Galvanised Welded Wire Mesh Fence Netting

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Konson
Certification: CE, ISO9001, SGS, ASTMA, EN, BS standard.
Model Number: KS-Gabion
Payment & Shipping Terms:
Minimum Order Quantity: 1000 sqm
Price: Discuss in mail
Packaging Details: weave bag,flat bundle,binding with steel strape or strands,some rolls.as your design.
Delivery Time: 10 days for 1x40 feet FCL
Payment Terms: L/C,T/T
Supply Ability: 12000 sqm per day
Detailed Product Description
Product Name: Wire Netting Fence Galvanized: Hot Dip Galvanized
Coating: PVC Coated Twist: Double Twist
Mesh Size: 60mm X 80mm... Max Width (mm): 4300mm...
High Light:

welded wire mesh

,

galvanized hexagonal wire mesh

Gabion Mesh PVC Woven Hexagonal Galvanised Welded Wire Mesh Fence Netting



Details:
Galvanized PVC hexagonal wire mesh is woven by the hexagonal mesh,  the diameter thickness  depends on the mesh size, the diameter is between 2.0mm to 4.0mm if the material is zinc coated, while the diameter will be 3.0mm to 4.5mm if the material is PVC-coated wire, the selvage wire diameter  usually is one gauge thicker than the body wire diameter.

Hexagonal Wire Netting Gabion Mesh With Electro Galvanizing And PVC Coated
Electro Galvanizing Hot Dip Galvanized And PVC Coated Double Twist Hexagonal Mesh Gabion Wire Netting


Engineering projects:

Gabion Mesh PVC Woven Hexagonal Galvanised Welded Wire Mesh Fence Netting 0

Specification:

 KS Hexagonal wire mesh

Mesh size
(mm)

Body Wire Dia.(mm)

Wire (PVC wire )/Inner/Outside
 Dia.(mm)

Max Width (mm)

60X80

2.0-2.8

2.0/3.0-2.5/3.5

4300

80X100

2.0-3.2

2.0/3.0-2.8/3.8

4300

80X120

2.0-3.2

2.0/3.0-2.8/3.8

4300

100X120

2.0-3.4

2.0/3.0-2.8/3.8

4300

100X150

2.0-3.4

2.0/3.0-2.8/3.8

4300

120X150

2.0-4.0

2.0/3.0-3.0/4.0

4300



Application:
1.Controlling and leading the river and flood
2.Flood discharge and lead flow
3.rock fall defending
4.preventing the water and soil lost
5.protecting the bridge
6.reinforce fabric
7.seashore recovery project
8.seaport project
9.block wall
10.defending the road.
