Fully Automatic Hexagonal Mesh Machine Making Straight and Reverse Twisted Wire Mesh
1. Introduction
Konson brand gabion mesh machine is the professional equipments for producing gabion basket, gabion wire mesh, it is also known as heavy type hexagonal wire netting machine.
Gabion mesh machine includes four main standard parts: Main netting machine, Winding machine, Wire tension device and Spiral coiling machine, it can produce gabions of various widths and mesh sizes.
Hexagonal Mesh Machine:
1. Model: KS80100-4.0
2. Mesh size: 80x100mm
3. Twist: Double twist
4. Wire diameter: 1.6-4.0mm
5. PVC wire diameter: 3.0-5.5mm
6. Max. width: 4300mm
7. Spindle Speed:25r/min
8. Theoretic output: 3.5m/min
9. Motor power: 22.0kw
10. Weight: 15MT
11. Dimensions: 8100mm x 1500mm x 2180mm
Specification:
KS machine is designed to produce hexagonal mesh of various widths and sizes:
