High Efficiency 22kw Hexagonal Gabion Mesh Machine 80x100mm Mesh Size
1. Introduction.
KONSON brand Gabion machine is designed to produce gabion mesh of various widths and mesh sizes.
Konson brand Gabion Machine is one kind of special equipment for twisting metal wire hexagonal mesh with big wire, large mesh and wide breadth. The product has widely function, with its good corrosion resistance and oxidation resistance, it serves well as strengthening, protection and temperature keeping materials in the form of mesh container, stone cage, isolation wall, boiler cover or poultry fence in construction, chemical, breeding, garden and food processing industries.
2.Specifications:
1. Mesh sizes: 80X100mm
2. Twist model: double twist & three twist
3. Max. netting width: 4300mm
4. Max. galvanized wire dia.: 3.9mm
5. Max PVC wire diameter: 4.9mm
6. Theoretic output: 255m/hr
7. Power: 22Kw
8. Dimensions: 8100 x 1400 x 2400mm
9. Weight: 15MT
10. Automatic oil system
11. Automatic stop system
12. Infrared ray safety system
All of the core parts of machines are processed by our own factory, the quality can be ensured.
