Metal Wire Mesh Gabion Box Stone Cage , Galvanized Welded Gabion Wire Mesh

Name: Metal Wire Mesh Gabion Box Stone Cage , Galvanized Welded Gabion Wire Mesh
Brand: Konson
SKU: KS-Gabion
Price: 1.00 USD
Availability: InStock
Rating: 4.8 (188 reviews)

Large Image : Metal Wire Mesh Gabion Box Stone Cage , Galvanized Welded Gabion Wire Mesh

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Konson
Certification:	CE, ISO9001, SGS, ASTM, EN, BS Standard.
Model Number:	KS-Gabion

Payment & Shipping Terms:

Minimum Order Quantity:	1000 sqm
Price:	Discuss in mail
Packaging Details:	weave bag,flat bundle,binding with steel strape or strands,some rolls.as your design.
Delivery Time:	10 days for 1x40 feet FCL
Payment Terms:	L/C,T/T
Supply Ability:	12000 sqm per day

Contact Now

Detailed Product Description

High Light:

gabions wire mesh

hexagonal mesh

Gabion Mesh Galfan PVC Coated Wire 2.7mm Stone Box For Coastal Protection

Gabions are cages, cylinders or boxes filled with soil or sand that are used in civil engineering, road building, and military applications. For erosion control caged riprap is used.For dams or foundation construction, cylindrical metal structures are used.

Konson Gabion by CE certification and ISO9001, SGS, ASTMA97597, EN 10223 standard within SGS.We are certain that the quality is better than other suppliers and can meet you request.

Hot Dip Galvanized Wire Hexagonal Stainless Steel Welded Wire Galfan Gabion Wire Mesh

Specification:

Opening(mm)	Wire diameter (mm)	Wire Diameter (PVC Coated)/ Inner/Outside(mm)	Size(m)
60x80	2.0-2.8	2.0/3.0-2.5/3.5	1x1x0.3 1x1x0.5 2x1x0.3 2x1x0.5 2x1x1 4x2x1 6x2x0.3 6x2x1 As your request
80x100	2.0-3.2	2.0/3.0-2.8/3.8
80x120	2.0-3.2	2.0/3.0-2.8/3.8
100x120	2.0-3.4	2.0/3.0-2.8/3.8
100x150	2.0-3.4	2.0/3.0-2.8/3.8
120x150	2.0-4.0	2.0/3.0-3.0/4.0

Details:

1.Certification:

ASTM A75-97, BS1052, EN-10223-3, YB/T4190-2009, ISO9001:2000, CE

2.Materials: Hot dip galvanized wire

Heavy zinc-coated wire(220-290g/m2 )

Pvc coated wire

Galfan wire

3.Coating: Zinc, PE, PVC, Zn-5-AL, Zn-10-Al

4.Gabion selvedge wire diameter: 2.2mm, 2.4mm, 2.7mm, 3mm, 3.4mm, 4mm

5.Gabion tie wire/lacing wire diameter: 2.2mm, 3%, 5%, 8% of weight

Gabion box used in:

1.Control and guide of water or flood , Preventing of rock breaking , Keep off dust wall

2.Rock fall protection , Water and soil protection , Port project, roadway protection

3.Bridge protection , Strengthening structure of soil

4.Protection engineering of seaside area.

When requesting a quotation, Please give me all the details:

Example:

Materials	Hot dip galvanized wire
Size of units (length x width x height)	2x1x1m
Quantity	6000 units
Opening mesh size	80x100mm
Type of coating	PVC
Mesh Diameter	2.7-3.7mm
Selvedge wire diameter	3.0-4.0mm
Tie wire/lacing wire diameter	2.2-3.2mm
Other	As your request.
