Auto High Speed Stone Gabion Mesh Machine With Wire Tension Device

China Auto High Speed Stone Gabion Mesh Machine With Wire Tension Device supplier

Large Image :  Auto High Speed Stone Gabion Mesh Machine With Wire Tension Device

Product Details:

Place of Origin: Jiangsu, China
Brand Name: Konson
Certification: CE, ISO9001, SGS, ASTMA, EN, BS standard.
Model Number: KS80100-3.2

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Discuss in mail
Packaging Details: One 40' Open Top Container, wooden pallet, as your design
Delivery Time: within 30 days in receiving prepayment
Payment Terms: L/C, T/T
Supply Ability: 10 Sets per Month
Contact Now
Detailed Product Description

Auto High Speed Stone Gabion Mesh Machine With Wire Tension Device

1. Introduction
The KS series gabion mesh machines include four main standard parts: Main netting machine, Winding machine, Wire tension device and Spiral coiling machine, it can produce gabions of various widths and mesh sizes.
Our company would like to wholeheartedly offer the customers good service and excellent products.
Auto High Speed Stone Gabion Mesh Machine With Wire Tension Device


KS Gabion Machine
1. Automatic, higher efficiency
2. Inside winding device
3. Overload protect clutch

4. CE certification
5. Fast delivery.


2.Specification

KS machine is designed to produce hexagonal mesh of various widths and sizes:

MODEL MESH SIZE MAX.WIRE DIA. MAX WIDTH PRODUCING RATE
KS6080-2.4

60X80

mm

3.0mm 2400mm >3.3 m/min
KS6080-3.2 3.5mm 3200mm
KS6080-4.0 3.5mm 4300mm
KS80100-2.4

80X100

mm

3.5mm 2400mm >3.5 m/min
KS80100-3.2 3.5mm 3200mm
KS80100-4.0 4.0mm 4300mm
KS100120-2.4

100X120

mm

3.5mm 2400mm >3.5 m/min
KS100120-3.2 3.5mm 3200mm
KS100120-4.0 4.0mm 4300mm
KS120150-2.4

120X150

mm

4.0mm 2400mm >3.8 m/min
KS120150-3.2 4.0mm 3200mm
KS120150-4.0 4.0mm 4300mm

We can also manufacture special size machine according to customer request.
