Double Twist Gabion Machine , Heavy Duty Hexagonal Wire Mesh Gabion Boxes Equipment

Certification
China Konson Industrial Co., Ltd. certification
We got three machines form KONSON,the machine is good quality and they provide service of installation and debugging.

—— Hassan Fehmi from Turkey

I imported 80,000 sets gabion boxes.The products and marketing team are both excellent.The gabion got a good mark in quality test.

—— Soriane Morchedi from Algeria

I'm Online Chat Now

Double Twist Gabion Machine , Heavy Duty Hexagonal Wire Mesh Gabion Boxes Equipment

Double Twist Gabion Machine , Heavy Duty Hexagonal Wire Mesh Gabion Boxes Equipment
Double Twist Gabion Machine , Heavy Duty Hexagonal Wire Mesh Gabion Boxes Equipment

Large Image :  Double Twist Gabion Machine , Heavy Duty Hexagonal Wire Mesh Gabion Boxes Equipment

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Konson
Certification: CE, ISO9001, SGS, BS,EN Standard.
Model Number: KS Prduction line
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Discuss in mail
Packaging Details: One 40' Open Top Container, wooden pallet, as your design
Delivery Time: within 30 days in receiving prepayment
Payment Terms: L/C, T/T
Supply Ability: 10 Sets per Month
Detailed Product Description
High Light:

gabion mesh machine

,

gabion making machine

Double Twist Gabion Machine , Heavy Duty Hexagonal Wire Mesh Gabion Boxes Equipment



1. Introduction

Konson brand gabion machine refers to the machine for making of hexagonal wire netting, it is also known as heavy type hexagonal wire netting machine. Our machine is specially used to produce the large size and heavy duty hexagonal (galvanized, galfan & PVC wire) wire meshes for the fence and the stone gabions usage. It has several models for different sizes of meshes and the maximum netting width is up to 4.3 meters. We can also supply the complete production line for your whole netting workshop.



Double Twist Gabion Machine , Heavy Duty Hexagonal Wire Mesh Gabion Boxes Equipment 0

KONSON brand Gabion machine is designed to produce gabion mesh and of various widths and mesh sizes. Konson brand Gabion Machine is one kind of special equipment for twisting metal wire hexagonal mesh with big wire, large mesh and wide breadth.



2.Specification:

MODEL MESH SIZE MAX.WIRE DIA. MAX WIDTH PRODUCING RATE
KS6080-2.4

60X80

mm

3.0mm 2400mm >3.3 m/min
KS6080-3.2 3.5mm 3200mm
KS6080-4.0 3.5mm 4300mm
KS80100-2.4

80X100

mm

3.5mm 2400mm >3.5 m/min
KS80100-3.2 3.5mm 3200mm
KS80100-4.0 4.0mm 4300mm
KS100120-2.4

100X120

mm

3.5mm 2400mm >3.5 m/min
KS100120-3.2 3.5mm 3200mm
KS100120-4.0 4.0mm 4300mm
KS120150-2.4

120X150

mm

4.0mm 2400mm >3.8 m/min
KS120150-3.2 4.0mm 3200mm
KS120150-4.0 4.0mm 4300mm



3.New Machine: KS80100-4.0

1. Mesh sizes: 80X100mm

2. Twist model: double twist & three twist

3. Max. netting width: 4300mm

4. Max. galvanized wire dia.: 3.9mm

5. Max PVC wire diameter: 4.9mm

6. Theoretic output: 255m/hr

7. Power: 22Kw

8. Dimensions: 8100 x 1400 x 2400mm

9. Weight: 15MT

10. Automatic oil system

11. Automatic stop system

12. Infrared ray safety system

All of the core parts of machines are processed by our own factory, the quality can be ensured.



Double Twist Gabion Machine , Heavy Duty Hexagonal Wire Mesh Gabion Boxes Equipment 1



Advantages of our machine:

A1. CE certificated.
A2. QC system & timely delivery.
A3. New drive mode.
A4. Automatic oil system.
A5. Overload protect clutch.
A6. High-efficiency: theoretic output = 3.5m/min.
A7. Turbine protection system (Option).
A8. Infrared ray safety (Option).
A9. Automatic stop system (Option).
A10. All of the core parts of machines are processed by our own factory, so the quality can be ensured.
A11. KONSON offer better after-sale service. We can provide 12 months guarantee for all the equipments, we will arrange our engineer to install the machines in your factory and teach your workers how to produce, we will also send accessories and spare parts without any cost.
