Double Rack Drive Gabion Box Machine For Water Conservancy Wire Mesh

Double Rack Drive Gabion Box Machine For Water Conservancy Wire Mesh
Double Rack Drive Gabion Box Machine For Water Conservancy Wire Mesh

Large Image :  Double Rack Drive Gabion Box Machine For Water Conservancy Wire Mesh

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Konson
Certification: CE, ISO9001, SGS test, Chinese Patent
Model Number: KS80100-4.0
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Discuss in mail
Packaging Details: One 40' Open Top Container, wooden pallet, as your design
Delivery Time: within 30 days in receiving prepayment
Payment Terms: L/C, T/T
Supply Ability: 10 Sets per Month
Detailed Product Description
High Light:

wire mesh machines

,

wire mesh welding machine

Double Rack Drive Gabion Box Machine For Water Conservancy Wire Mesh





1. Introduction

Gabion Box Machine:

The KS series automatic gabion machine includes four main standard parts: Main netting machine, winding machine, wire tension device and spiral coiling machine, it can produce gabions of various widths and mesh sizes.

MODEL

MESH SIZE

MAX.WIRE DIA.

MAX WIDTH

PRODUCING RATE

KS6080-2.4

60X80

mm

3.0mm

2400mm

>3.3 m/min

KS6080-3.2

3.5mm

3200mm

KS6080-4.0

3.5mm

4300mm

KS80100-2.4

80X100

mm

3.5mm

2400mm

>3.5 m/min

KS80100-3.2

3.5mm

3200mm

KS80100-4.0

4.0mm

4300mm

KS100120-2.4

100X120

mm

3.5mm

2400mm

>3.5 m/min

KS100120-3.2

3.5mm

3200mm

KS100120-4.0

4.0mm

4300mm

KS120150-2.4

120X150

mm

4.0mm

2400mm

>3.8 m/min

KS120150-3.2

4.0mm

3200mm

KS120150-4.0

4.0mm

4300mm

Double Rack Drive Gabion Box Machine For Water Conservancy Wire Mesh 0

2. KS Gabion Net Production line

Standard Machines:
1. Main netting machine
2. Winding machine
3. Wire tension device
4. Spiral coiling machine

Optional Machines:
5. Hydraulic packing machine
6. Wire spools
7. Work platform
8. Netting straightening machine
9. Netting cutting machine
10. Wrapped edge machine
11. Selvedge cutting machine
12. PVC coating line
