High Efficiency Gabion Machine Hexagonal Fence Making Equipment

: Large Image : High Efficiency Gabion Machine Hexagonal Fence Making Equipment

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	Konson
Certification:	CE, ISO9001, SGS, ASTMA, EN, BS standard.
Model Number:	KS80100-3.2

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Discuss in mail
Packaging Details:	One 40' Open Top Container, wooden pallet, as your design
Delivery Time:	within 30 days in receiving prepayment
Payment Terms:	L/C, T/T
Supply Ability:	10 Sets per Month

Contact Now

Detailed Product Description

High Efficiency Gabion Machine Hexagonal Fence Making Equipment

1. Introduction

The KS series gabion mesh machines include four main standard parts: Main netting machine, Winding machine, Wire tension device and Spiral coiling machine, it can produce gabions of various widths and mesh sizes.

KS Gabion Machine
1 automatic, higher efficiency
2 inside winding device
3 overload protect clutch

4 CE certification

High Efficiency Gabion Machine Hexagonal Fence Making Equipment

2.Specification

KS machine is designed to produce hexagonal mesh of various widths and sizes:

MODEL	MESH SIZE	MAX.WIRE DIA.	MAX WIDTH	PRODUCING RATE
KS6080-2.4	60X80 mm	3.0mm	2400mm	>3.3 m/min
KS6080-3.2		3.5mm	3200mm
KS6080-4.0		3.5mm	4300mm
KS80100-2.4	80X100 mm	3.5mm	2400mm	>3.5 m/min
KS80100-3.2		3.5mm	3200mm
KS80100-4.0		4.0mm	4300mm
KS100120-2.4	100X120 mm	3.5mm	2400mm	>3.5 m/min
KS100120-3.2		3.5mm	3200mm
KS100120-4.0		4.0mm	4300mm
KS120150-2.4	120X150 mm	4.0mm	2400mm	>3.8 m/min
KS120150-3.2		4.0mm	3200mm
KS120150-4.0		4.0mm	4300mm

We can also manufacture special size gabion machine according to customer request.
1.Various models to choose
2.Max.width 4000mm
3.Automatic&Low noise
4.High effectivenes
