Orrosion Resistant Galvanised Gabion Mesh River Gabion Mattress 100 x 120mm Mesh Size

Orrosion Resistant Galvanised Gabion Mesh River Gabion Mattress 100 x 120mm Mesh Size
Orrosion Resistant Galvanised Gabion Mesh River Gabion Mattress 100 x 120mm Mesh Size

Large Image :  Orrosion Resistant Galvanised Gabion Mesh River Gabion Mattress 100 x 120mm Mesh Size

Product Details:
Place of Origin: Jiangsu, China
Brand Name: Konson
Certification: CE, ISO9001, SGS, ASTMA, EN, BS standard.
Model Number: KS-GM
Payment & Shipping Terms:
Minimum Order Quantity: 1000 sqm
Price: Discuss in mail
Packaging Details: weave bag,flat bundle,binding with steel strape or strands,some rolls.as your design.
Delivery Time: 10 days for 1x40 feet FCL
Payment Terms: L/C,T/T
Supply Ability: 12000 sqm per day
Detailed Product Description
High Light:

gabions wire mesh

,

hexagonal mesh

Customized Galvanised Gabion Mesh River Gabion Mattress 100 x 120mm Mesh Size



Gabion mattress is a structure made of hexagonal double twisted wire mesh, gabion mattresses are filled with stones at the project site to form flexible and permeable, monolithic structures such as river bank protection and channel linings for erosion control.Gabion mattresses are divided into uniformly partitioned cells by internal diaphragms.

Gabion Mattresses size:
Standard sizes 6x2x0.17m  6x2x0.23m   6x2x0.30m  3x2x0.17m  3x2x0.23m  3x2x0.30m
Mesh size(mm):60x80mm, 80x100mm, 100x120mm, 120x150mm
Wire diameter:2.2mm/3.2mm, 2.4mm/3.4mm, 2mm/3.0mm
We can manufacture as client's demand.



Orrosion Resistant Galvanised Gabion Mesh River Gabion Mattress 100 x 120mm Mesh Size 0


Gabion mattresses specification:

Long(m)

Width(m)

High(m)

Mesh type(mm)

3m

2m

0.15-0.20-0.25

80x100

4m

2m

0.15-0.20-0.25

80x100

5m

2m

0.15-0.20-0.25

80x100

6m

2m

0.15-0.20-0.25

80x100

3m

2m

0.17-0.23-0.30

60x80

4m

2m

0.17-0.23-0.30

60x80

5m

2m

0.17-0.23-0.30

60x80

6m

2m

0.17-0.23-0.30

60x80

All sizes and dimensions are nominal. Tolerances of ± 3% of the width,  length,

and ±2.5 cm of the height shall be permitted.



1. Flexible. It can tolerate huge forces without breaking or cracking. It can adapt itself to some degree of movement.
2. Durable. If coated with PVC, the life of structure gets longer which is better for hydraulic works.
3. Permeable. Gabion box filled with stones provides an effective permeability throughout the structure.
4. Economical. Especially when the stones to fill the structure are close to the work area. Low maintenance is required for the construction works.
5. Strength. It can absorb the huge amount of energy and is very strong under tension generated by the nature.Well-made gabion structures can exist in perfect condition for many decades.
